Mac Pro features a modular graphics expansion architecture called the Mac Pro Expansion Module, or MPX Module, that delivers more power and bandwidth and integrates Thunderbolt throughout the system. You can choose one or two MPX Modules to configure the graphics in your Mac Pro, or add MPX Modules later to change or upgrade your Mac Pro graphics capabilities.
AMD Radeon Pro 580X
For great all-around graphics performance, choose the AMD Radeon Pro 580X with 8GB of GDDR5 memory. It features up to 5.6 teraflops of performance and supports up to six 4K displays, two 5K displays, or two Pro Display XDRs. And the half-height MPX Module fits in an MPX bay and enables PCIe slot 2 for additional expansion.
AMD Radeon Pro W5700X
For even better performance, choose the Radeon Pro W5700X with 16GB of GDDR6 memory. This full-size MPX Module is based on AMD’s new RDNA architecture, and it features up to 9.4 teraflops of single-precision or 18.9 teraflops of half-precision computing. It supports up to six 4K displays, three 5K displays, or three Pro Display XDRs. And you also get four Thunderbolt 3 ports and one HDMI 2.0 port.
AMD Radeon Pro Vega II
For workstation-class graphics and demanding pro applications, choose the AMD Radeon Pro Vega II with 32GB of HBM2 memory delivering up to 1TB/s memory bandwidth. You can install up to two in your Mac Pro using Infinity Fabric Link for applications like Final Cut Pro X, which utilizes enhanced multi-GPU performance. This graphics option also features up to 14.1 teraflops of single-precision or 28.3 teraflops of half-precision computing. It supports up to six 4K displays, three 5K displays, or two Pro Display XDRs. And the full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth to deliver four additional Thunderbolt 3 ports and an HDMI 2.0 port on the card. When you select the option with two Vega II GPUs, the Infinity Fabric Link connector comes preinstalled.
AMD Radeon Pro Vega II Duo
To push your graphics performance even further, choose the Radeon Pro Vega II Duo, which is ideal for even the most demanding multi-GPU pro applications. The module has two Vega II GPUs on the board, each with 32GB of HBM2 memory delivering up to 1TB/s memory bandwidth; the two GPUs are connected with Infinity Fabric Link. Install two modules in your Mac Pro for intensive tasks like GPU rendering. Get up to 28.3 teraflops of single-precision or 56.6 teraflops of half-precision computing. It supports up to eight 4K displays, four 5K displays, or four Pro Display XDRs. And the full-height MPX Module fills an MPX bay and uses extra power and PCIe bandwidth to deliver four additional Thunderbolt 3 ports and an HDMI 2.0 port on the card.
